Specifications

EasyConnect MPX 200
ECM1001*
Evoko Delo connection manager infographic

General

Model name:
EasyConnect MPX 200
Warranty
3 years*
Type:
Presentation system

Article numbers

EasyConnect MPX 200 (EU cable):
ECM10001EU
EasyConnect MPX 200 (US cable):
ECM10001US
EasyConnect MPX 200 (UK cable):
ECM10001UK

Features

No data was found

Connectivity

Cables
4pcs USB 3.1 Gen 2 C to C:
Max 20V 5A 100W
Length 2m, 1m above table
Power supply
Input:
85 – 264V AC, 2,4A max, 1 meter AC-cord included.
Output:
20V DC, 10A, 4-Pin DIN with locking mechanism.
Power:
180W Max (4x USB-A + 4x USB-C)
Connectivity hub
USB Devices:
2x USB-A 3.0 sockets for connecting devices such as speakers and cameras.
HDMI:
HDMI 2.0 for connecting display or projector.
Wifi (management only):
2.4GHz, 802.11 n
Ethernet (management only):
RJ45, 100Mbit/s, Full-duplex

Functionality

USB-C Video In
Alt-Mode Display-Port 1.1 to 1.4 2 or 4 lanes (configurable). Max bandwith 32 Gbit/s Up to HDR3
HDMI Video Out
HDMI 2.0b. HDCP 1.4 and 2.3. Max 18 Gbit/s output.
2 DP Lane mode: DP1.2 = 4K30Hz, DP 1.4 = 4K60Hz.
4 DP Lane mode: DP 1.2 = 4K60Hz.
USB Pass-through
2 DP Lane mode: USB 2.0 LS/FS/HS & USB 3.1, SS/5 Gbit/s.
4 DP Lane mode: USB 2.0 LS/FS/HS Charging USB-C: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 19,5V/5A, 20V/5A

Measurements and weights

Evoko Delo connection manager infographic
Main unit
Width:
83 mm
(3.3 inches)
Height:
20 mm
(0.8 inches)
Depth:
83 mm
(3.3 inches)
Cable:
Up to 1m cable above table
Frame 933
Cable bag
Width:
130 mm
(5.1 inches)
Height:
650 mm
(25.6 inches)
Depth:
230 mm
(9.1 inches)
Sales kit
Retail sales kit package
Width:
310 mm
(12.2 inches)
Height:
290 mm
(11.4 inches)
Depth:
120 mm
(4.7 inches)
Weight:
4 kg
(8.82 lbs)

Software

EasyConnect management console, PC application.
In room or pre-installation management of the EasyConnect MPX 200.
Setup Ethernet or Wifi for FW-updates and online management.
Choose between different setups such as BYOD, integrated MTR or PC-based MTR.

Compatible platforms

Google Meet
Microsoft Teams
Zoom
Barco ClickShare
And more...

Installation

Meeting room table
Choose screws or other fastening hardware depending on table material.
Table thickness: 5 – 45 mm.
For the controller and cable outlet a ø75mm hole is required in the table.

In the box

Touch controller with light guide
Included
Connectivity hub
Included
4x USB-C to C cables
Included
Cable bag
Included
Power supply
Included
Cable weights
Included
Mounting hardware
Included

Warranty and service

Evoko offers a standard two year warranty for all products from the date of purchase free of charge.
It is possible to extend the warranty period with up to 3 additional years at an additional cost, making the maximum total warranty period 5 years from the date of purchase.
